Izzo Pizzaiolo

The Multi-Chamber Solution for Maximum Output.


Handmade in Naples - The heart of pizza

For pizzerias working at the limits of their capacity, the Pizzaiolo series is the ultimate answer. These pre-assembled multi-chamber powerhouses have been designed for the highest production volumes without compromising on the quality of authentic Neapolitan pizza.

The Heart of Every Pizzaiolo

Every model, regardless of its size, is built around the same uncompromising core technologies. This is the professional DNA that guarantees you consistent, top-tier quality.

Flexible Capacity & Control

Choose between 2 or 3 chambers and control each one individually. Run different temperature profiles simultaneously or switch off unused chambers to save energy.

Biscotto Deck as Standard

Each baking chamber comes standard with the authentic "Biscotto di Sorrento" clay deck—for perfect pizza bases at 470°C.

Complete System

Comes standard with a robust base and an integrated, fully functional holding cabinet.

Uncompromising Performance

Up to 470°C, hand-laid heating elements, and massive insulation guarantee unparalleled, high-volume baking results.

Hover over the pulsing dots to discover the key features of the Izzo Pizzaiolo.

Biscotto Deck (Standard)

The 40mm thick clay brick deck is the industry standard for authentic Neapolitan pizza at 470°C.

Separate Chamber Control

Each baking chamber can be activated individually and operated with its own temperature profile.

Base & Holding Cabinet

Delivered complete with a robust base and an integrated, heated cabinet.

Special Door Insulation

Minimizes heat loss and ensures constant baking temperatures, even with frequent opening.

Technical Datasheets

Explore the detailed technical information for the Izzo Pizzaiolo and discover its full specifications.

Which Pizzaiolo is Right for You?

Answer one simple question to find your perfect multi-chamber solution.

How many pizzas do you bake per hour during peak times?

Izzo Pizzaiolo with 2 chambers

Your Recommendation: Pizzaiolo with 2 Chambers

The perfect solution for busy pizzerias. Two individually controlled baking chambers give you the capacity and flexibility to deliver top quality consistently, even during peak hours.

Details for 2-Chamber Model
Izzo Pizzaiolo with 3 chambers

Your Recommendation: Pizzaiolo with 3 Chambers

The ultimate powerhouse for establishments with extremely high production volumes. With three baking chambers, you are prepared for any rush and can maximize your production capacity.

Details for 3-Chamber Model

AT A GLANCE

Hand-Laid Heating Elements

Carefully hand-laid nichrome heating coils guarantee exceptionally even and intense heat.

Integrated Control

The advanced control panel is ergonomically integrated into the base, allowing full control over each individual chamber.

Superior Efficiency

Excellent insulation ensures constant temperatures during continuous operation and high residual heat the next day.

Smart Automation

Use the integrated cooking timer and programmable on/off times for perfectly plannable workflows.

Good to Know

For detailed information on the use, cleaning, and maintenance of your machine, we recommend consulting the user manual and operating instructions. There, you will find precise descriptions for this model. The document is available for download above and is also linked in the article.

  • Smoki Junior: Filters smoke emissions from wood-fired ovens (e.g., in pizzerias or restaurants) and reduces particles through water spray technology.
  • Smoki Maxi: Filters smoke particles from wood, coal, or biomass ovens (e.g., in pizzerias, bakeries) and reduces environmental impact via water spray.
  • Smoki Maxi Grill: Filters soot and grease particles from smoke emissions of charcoal or wood-fired grills (e.g., in restaurants or food stalls) using water spray.
  • Smoki Junior & Maxi: Filters approximately 60–70% of smoke color and 40–50% of odor.

  • Smoki Maxi Grill: Filters approximately 60–70% of smoke color, 40–50% of odor, and 90–95% of soot.

  • Smoki Junior: On identification plate. See Chapter 3.4 of manual.

  • Smoki Maxi: On identification plate at front of unit. See Chapter 4.1

  • Smoki Maxi Grill: On identification plate (location see Chapter 3.4 of manual)

  • Several options available:

    • Smoki Junior:

      • Indoor: Direct connection to chimney, either beside or above the oven

      • Outdoor: Roof installation with weatherproof cover (optional)
        Details in Chapter 8.2.4

    • Smoki Maxi:

      • Indoor: Direct connection to chimney, above or beside the oven

      • Outdoor: Roof installation with optional insulation cover (required below -10°C)
        Details: Chapter 13

    • Smoki Maxi Grill:

      • Indoor: Connection to chimney at any point between grill and roof

      • Outdoor: Roof installation with weatherproof cover (optional)
        Details in Chapter 8.2.4

  • Smoki Junior: Smooth stainless steel pipes (AISI 316) with diameters of 160, 180, 200 or 250 mm

  • Smoki Maxi: Smooth stainless steel pipes (AISI 316) with 5° slope for optimal smoke extraction (see Chapter 10.3)

  • Smoki Maxi Grill: Smooth stainless steel pipes (AISI 316) with diameters of 250, 350, 400, 500 or 600 mm

  • Smoki Junior & Maxi Grill:

    1. Check water connection (1.5-3 Bar) and wastewater connection

    2. Connect power supply (220V, 50-60Hz)

    3. Set main switch and circuit breaker to "ON"
      See Chapter 10.2.

  • Smoki Maxi:

    1. Check water connection (1.5-3 Bar) and wastewater connection

    2. Connect power supply (380V, 50-60Hz)

    3. Set main switch and machine power switch to "ON"
      See Chapter 10.6.

Possible causes:

  • No power (check switch)

  • Insufficient water in tank (wait 10 minutes after filling)

  • Faulty level sensor

  • Smoki Junior & Maxi Grill:See Chapter 13.2.

  • Smoki Maxi:See Chapter 14.

  • Open water valve

  • Check pressure gauge for defects

Every 15 days (see maintenance schedule).
  1. Turn off power and water supply

  2. Open drain valve

  3. Remove cover (release fasteners) and clean tank manually

  • Smoki Junior & Maxi Grill:See Chapter 11.3.

  • Smoki Maxi:See Chapter 12.11.

Remove debris manually and check drain.

  • Clogged maintenance nozzle (clean)

  • Faulty level sensor

Water level too high. Possible causes:

  • Faulty fill valve

  • Clogged overflow

  • Smoki Junior & Maxi Grill:See Chapter 13.2.

  • Smoki Maxi:See Chapter 14.

  • Smoki Junior & Maxi Grill: In manual appendix (Chapter 14).

  • Smoki Maxi: In appendix (Chapter 15).

  • Only trained personnel may perform maintenance.

  • Disconnect power before servicing.

  • Wear PPE (gloves, safety goggles).

  • Smoki Junior & Maxi Grill:See Chapter 6.

  • Smoki Maxi:See Chapter 7.

No. Unauthorized modifications or improper maintenance will void the warranty.

Remove filter element and clean with water jet (every 15-30 days). See Chapter 12.8.

  • Smoki Junior: Clean nozzle with water/compressed air (every 6 months).

  • Smoki Maxi: Remove nozzle with 26mm wrench and clean with water/compressed air (every 6 months). See Chapter 12.12.

Every 6 months (special maintenance). Clean with water or compressed air.
